| CPU | LGA1151 socket for 8th Generation Intel® Core™ i7/ i5/ i3, Pentium® and Celeron® processors |
| Supports 14nm CPU | |
| Supports Intel® Turbo Boost Technology 2.0* | |
| * The Intel® Turbo Boost Technology 2.0 support depends on the CPU types. | |
| ** Refer to www.asus.com for Intel® CPU support list. | |
| Chipset | Intel® H370 Chipset |
| Memory | 4 x DIMM, maximum 64 GB, DDR4 2666/ 2400/ 2133MHz, non-ECC, unbuffered memory |
| Dual channel memory architecture | |
| Supports Intel® Extreme Memory Profile (XMP) | |
| * The maximum memory frequency supported varies by processor. | |
| ** DDR4 2666MHz and higher memory modules will run at max. 2666MHz on Intel® 8th Gen. 6-core or higher processors. | |
| *** Refer to www.asus.com for the latest Memory QVL (Qualified Vendors List). | |
| Expansion Slots | 1 x PCI Express 3.0/2.0 x16 slot (at x 16 mode) |
| 1 x PCI Express 3.0/2.0 x16 slot (max. at x4 mode, compatible with PCIe x1, x2 and x4 devices) | |
| 2 x PCI Express 3.0/2.0 x1 slots | |
| 2 x PCI slots | |
| Multi-GPU Support | Supports AMD® CrossFireX™ Technology |
| VGA | Integrated Graphics Processor- Intel® HD Graphics support |
| Multi-VGA output support: HDMI/DVI-D/D-sub port | |
| – Supports HDMI 1.4b with max. resolution 4096 x 2160@24Hz / 2560 x 1600@60Hz | |
| – Supports DVI-D with max. resolution of 1920 x 1200 @60Hz | |
| – Supports D-sub with max. resolution 1920 x 1200@60Hz | |
| Supports Intel® InTru™ 3D/Quick Sync Video/Clear Video HD Technology/Insider™ | |
| Supports up to 3 displays simultaneously | |
| Maximum shared memory of 1024 MB (for iGPU exclusively) | |
| Storage | Intel® H370 Chipset with RAID 0, 1, 5, 10 and Intel Rapid Storage Technology support |
| – 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (SATA mode & X2 PCIE mode)* | |
| – 1 x M.2 Socket 3 with M Key, type 2242/2260/2280 storage devices support (X4 PCIE mode) | |
| – 6 x SATA 6.0 Gb/s ports (gray) | |
| – Intel® Optane™ Memory Ready | |
| * When a device in SATA mode is installed on the M.2_1 socket, SATA_2 port cannot be used. | |
| LAN | Realtek® 8111H Gigabit LAN support LANGuard |
| Audio | Realtek® ALC887 8-channel* high definition audio CODEC |
| – Audio Shielding: Ensures precision analog/digital separation and greatly reduces multi-lateral interference | |
| – Dedicated audio PCB layers: Separate layers for left and right channels to guard the quality of the sensitive audio signals | |
| – Premium Japanese audio capacitors: Provide warm, natural and immersive sound with exceptional clarity and fidelity. | |
| – Supports jack-detection and front panel jack-retasking | |
| * Choose the chassis with HD audio module in front panel to support 8-channel audio output. | |
| USB | Intel® H370 Chipset |
| – 2 x USB 3.1 Gen 2 (up to 10Gbps) ports (2 ports @back panel, teal blue, Type A) | |
| – 6 x USB 3.1 Gen 1 (up to 5Gbps) ports (4 ports @mid-board; 2 ports @back panel, blue, Type A) | |
| – 6 x USB 2.0/1.1 ports (4 ports @mid-board; 2 ports @back panel) | |
| ASUS Special Features | ASUS 5X PROTECTION III |
| – ASUS SafeSlot Core: Fortified PCIe with solid soldering | |
| – ASUS LANGuard: Protects against LAN surges, lightning strikes and static-electricity discharges! | |
| – ASUS Overvoltage Protection: World-class circuit-protecting power design | |
| – ASUS Stainless-Steel Back I/O: 3X corrosion-resistance for greater durability! | |
| – ASUS DIGI+ VRM: 6 Phase digital power design | |
| Superb Performance | |
| ASUS OptiMem | |
| – Improved DDR4 stability | |
| M.2 onboard | |
| – The latest transfer technologies with up to 32Gb/s data transfer speeds | |
| ASUS Fan Xpert 2+ | |
| – Ultimate cooling and quietness | |
| ASUS EPU | |
| – EPU | |
| UEFI BIOS | |
| – Most advanced options with fast response time | |
| Gaming Scenario | |
| Audio Features | |
| – Audio that roars on the battlefield | |
| ASUS Exclusive Features | |
| – ASUS Ai Charger | |
| – ASUS AI Suite 3 | |
| – ASUS file transfer | |
| – ASUS PC Cleaner | |
| EZ DIY | |
| UEFI BIOS EZ Mode | |
| – featuring friendly graphics user interface | |
| – ASUS CrashFree BIOS 3 | |
| – ASUS EZ Flash 3 | |
| Q-Design | |
| – ASUS Q-DIMM | |
| – ASUS Q-Slot | |
| ASUS Quiet Thermal Solution | Quiet Thermal Design: |
| – ASUS ASUS Fan Xpert 2+ | |
| – Stylish Fanless Design: PCH Heat-sink & MOS Heat-sink | |
| Back Panel I/O Ports | 1 x PS/2 keyboard/mouse combo port |
| 1 x HDMI port | |
| 1 x DVI-D port | |
| 1 x D-sub port | |
| 1 x LAN (RJ45) ports | |
| 2 x USB 3.1 Gen 2 (up to 10Gbps) Type A (teal blue) | |
| 2 x USB 3.1 Gen 1 (up to 5Gbps) Type A (blue) | |
| 2 x USB 2.0/1.1 ports | |
| 3-Jack 8-Channel Audio I/O ports | |
| Internal I/O Connectors | 2 x USB 3.1 Gen 1 (up to 5Gbps) connectors support additional 4 USB ports (19-pin) |
| 2 x USB 2.0 connectors support additional 4 USB ports | |
| 6 x SATA 6.0 Gb/s connectors (gray) | |
| 2 x M.2 Socket 3 (for M Key) | |
| 1 x 4-pin CPU Fan connector (PWM mode) | |
| 3 x 4-pin Chassis Fan connectors for 3-pin (DC mode) and 4-pin (PWM mode) coolers control | |
| 1 x Front panel audio connector (AAFP) | |
| 1 x Mono Out header | |
| 1 x System panel connector | |
| 1 x S/PDIF out header | |
| 1 x Chassis Intrusion connector* | |
| 1 x TPM header | |
| 1 x COM Header | |
| 1 x 24-pin EATX Power connector | |
| 1 x 8-pin EATX 12V Power connector | |
| 1 x Clear CMOS jumper | |
| * Chassis intrusion header is built in the system panel connector. | |
| BIOS | 128 Mb Flash ROM, UEFI AMI BIOS, PnP, SM BIOS 3.1, ACPI 6.1, Multi-language BIOS, ASUS EZ Flash 3, CrashFree BIOS 3, F11 EZ Tuning Wizard, F6 Qfan Control, F3 My Favorites, Last Modified log, F12 PrintScreen, and ASUS DRAM SPD (Serial Presence Detect) memory information |
| Manageability | WOL by PME, PXE |
| Accessories | 2 x SATA 6Gb/s cables |
| 1 x IO Shield | |
| 2 x M.2 screws | |
| 1 x Support DVD | |
| 1 x User’s manual | |
| Support DVD | Drivers |
| ASUS Utilities | |
| ASUS EZ Update | |
| Anti-virus software (OEM version) | |
| Operating System Support | Windows® 10 (64-bit) |
| Form Factor | ATX form factor: 12.0 in. x 8.7 in. (30.5 cm x 22.1cm) |
